Home > Cylindrical roller bearings > SL182206 INA 30x62x20mm Relubricatable Yes Cylindrical roller bearings
SL182206 INA 30x62x20mm  Relubricatable Yes Cylindrical roller bearings

SL182206 INA 30x62x20mm Relubricatable Yes Cylindrical roller bearings

Bearing numberSL182206Size (mm)30x62x20BrandINABore Diameter (mm)30Outer Diameter (mm)62Width (mm)20d30 mmD62 mmB20 mmD150.6 mmd142 mmE55.19 mmrmin1 mms1 mm / Axial displacementm0.3 kg / WeightCr70000 N / Dynamic load rating (radial)C0r64000 N / Static load rating (radial)Cur10200 N / Fatigue limit load. radialnG7400 1/min / Limiting speedCategoryC…
Contact Us Now !

Product description

SL182206 INA 30x62x20mm Relubricatable Yes Cylindrical roller bearings

Bearing numberSL182206
Size (mm)30x62x20
BrandINA
Bore Diameter (mm)30
Outer Diameter (mm)62
Width (mm)20
d30 mm
D62 mm
B20 mm
D150.6 mm
d142 mm
E55.19 mm
rmin1 mm
s1 mm / Axial displacement
m0.3 kg / Weight
Cr70000 N / Dynamic load rating (radial)
C0r64000 N / Static load rating (radial)
Cur10200 N / Fatigue limit load. radial
nG7400 1/min / Limiting speed
CategoryCylindrical Roller Bearings
BDI Inventory0.0
Manufacturer NameSCHAEFFLER GROUP
Minimum Buy QuantityN/A
Weight / Kilogram0.35
EAN4012802254266
Product Group – BDIB04144
Bore ProfileStraight
Cage MaterialNone
Precision ClassRBEC 1 | ISO P0
Number of Rows of RollersSingle Row
SeparableNo
Rolling ElementCylindrical Roller Bearing
ProfileComplete with Outer and Inner Ring
Snap RingNo
Internal ClearanceC0-Medium
RetainerNo
RelubricatableYes
Inch – MetricMetric
Other FeaturesFull Complement | 2 Rib Inner Ring | 1 Rib Outer Ring with Retaining Ring | Operating Temperature From -30 to 120 Deg
Long Description30MM Bore; Straight Bore Profile; 62MM Outside Diameter; 20MM Width; RBEC 1 | ISO P0; Single Row; Not Separable; No Snap Ring; Relubricatable; C0-Medium Internal Clearance; No Retainer
Category – BDICylindrical Roller Bearing
UNSPSC31171547
Harmonized Tariff Code8482.50.00.00
NounBearing
Manufacturer URLhttp://www.ina.com
Manufacturer Item NumberSL182206
Weight / LBS0.766
Width0.787 Inch | 20 Millimeter
Outside Diameter2.441 Inch | 62 Millimeter
Bore1.181 Inch | 30 Millimeter

Cross-reference to other manufacturer’s part number

ZB1.20.0644.200-1SPTN Thrust ball bearings

Fi:605 mm , Fe:690 mm , Ne:36 mm , Ni:36 mm
20210 Spherical roller bearings

Outer Diameter :90mm , Width :20mm , d:50 mm , D:90 mm , C:20 mm , B:20 mm
23136EAW33 Thrust roller bearings

H:96.000 mm , Width :96.000mm , D:300.000 mm , Bore Diameter :180.000mm , Outer Diameter :300.000mm , d:180.000 mm
T-M249748D/M249710+A Tapered roller bearings

d:254 mm , Width :130.175mm , D:358.775 mm , T:130.175 mm
KN3068-PP Linear bearings

B1:48 mm , Basic dynamic load rating (C):3.2 kN , B:68 mm , Weight:0.185 Kg
110055/110098XH Tapered roller bearings

da:70 mm , Weight:2.005 Kg , J:102.93 mm , R:2 mm , L:7 mm
2307 Self aligning ball bearings

Basic static load rating (C0):11.2 kN , r1 min.:1.5 mm , Weight:0.74 Kg , r2 min.:1.5 mm , C:31 mm , Basic dynamic load rating (C):39.5 kN
2910 Thrust ball bearings

Bore 2:1.976 Inch | 50.19 Millimeter , Height:0.709 Inch | 18 Millimeter , Outside Diameter:2.913 Inch | 74 Millimeter , Bore 1:1.969 Inch | 50 Millimeter
VLU 20 0944 Thrust ball bearings

Static load rating radial (C0):250 kN , Dynamic load rating axial (C):231 kN , DaZT:1046 mm , Weight:54 Kg , Dynamic load rating radial (C):151 kN
3206-B-2RSR-TV Angular contact ball bearings

Basic dynamic load rating (C):28.2 kN , Weight:0.3 Kg , Limiting speed:7500 r/min , r2 min.:1 mm , Basic static load rating (C0):20.2 kN , r1 min.:1 mm
