SS7212 CD/HCP4A SKF 60x110x22mm  rb max. 0.6 mm Angular contact ball bearings

SS7212 CD/HCP4A SKF 60x110x22mm rb max. 0.6 mm Angular contact ball bearings

Bearing numberSS7212 CD/HCP4ASize (mm)60x110x22BrandSKFBore Diameter (mm)60Outer Diameter (mm)110Width (mm)22d60 mmD110 mmB22 mmC22 mma22 mmd176.4 mmr1 min.1.5 mmr2 min.1.5 mmr3 min.0.6 mmr4 min.0.6 mmD196.8 mmda min.69 mmDa max.101 mmdb min69 mmra max.1.5 mmrb max.0.6 mmDb max105.8 mmWeight0.71 KgBasic dynamic load rating (C)57.2 kNBasic static lo…
Contact Us Now !

Product description

SS7212 CD/HCP4A SKF 60x110x22mm rb max. 0.6 mm Angular contact ball bearings

Bearing numberSS7212 CD/HCP4A
Size (mm)60x110x22
BrandSKF
Bore Diameter (mm)60
Outer Diameter (mm)110
Width (mm)22
d60 mm
D110 mm
B22 mm
C22 mm
a22 mm
d176.4 mm
r1 min.1.5 mm
r2 min.1.5 mm
r3 min.0.6 mm
r4 min.0.6 mm
D196.8 mm
da min.69 mm
Da max.101 mm
db min69 mm
ra max.1.5 mm
rb max.0.6 mm
Db max105.8 mm
Weight0.71 Kg
Basic dynamic load rating (C)57.2 kN
Basic static load rating (C0)46.5 kN
(Grease) Lubrication Speed16 000 r/min
Fatigue load limit (Pu)2

Cross-reference to other manufacturer’s part number

XR678052 Thrust roller bearings

T:63.5 mm , Outer Diameter :457.2mm , Width :63.5mm , D:457.2 mm , d:330.2 mm
260RIJ802 Cylindrical roller bearings

C:127 mm , r max:6 mm , E:903 mm , B:127 mm , D:958.85 mm
22218EF800 Thrust roller bearings

Outer Diameter :160.000mm , H:40.000 mm , d:90.000 mm , Width :40.000mm , D:160.000 mm
1109KLL Deep groove ball bearings

S:21.43 mm , Weight:0.767 Kg , Basic dynamic load rating (C):36.2 kN , L:4.76 mm
15590/15520 Tapered roller bearings

Weight (g):196.00 , Material:52100 chrome steel or equiavelent , Radius (min) (rs1):0.059 , Radius (min) (rs):0.138 , Inner Width (Bi):0.6875
35TAB07DF-2NK Thrust ball bearings

Starting Torque – Grease Lubrication:25 N·cm , Da2:64.9 mm , da2:49.7 mm , Da1:57.5 mm , da1:56.2 mm , Static Load Rating:12.200 N
SCE3220 Needle roller bearings

D:60.325 mm , C:31.75 mm , Weight:0.138 Kg , Basic dynamic load rating (C):55 kN , Basic static load rating (C0):116 kN
20206 KC Spherical roller bearings

C:16 mm , Basic dynamic load rating (C):27.5 kN , (Grease) Lubrication Speed:4000 r/min , Basic static load rating (C0):28.5 kN , Weight:0.228 Kg
15118/15250X Tapered roller bearings

Width :20.638mm , Brand:Fersa , d:30.213 mm , D:63.5 mm , Outer Diameter :63.5mm , Bore Diameter :30.213mm
7E-HVS25X33X25/LP03 Needle roller bearings

D:33 mm , Outer Diameter :33mm , Width :25mm , d:25 mm , Bore Diameter :25mm , Brand:NTN
