TSM 15-00 BB-E ISB Angle 6.5 °  Self aligning ball bearings

TSM 15-00 BB-E ISB Angle 6.5 ° Self aligning ball bearings

Bearing numberTSM 15-00 BB-EBrandISBBore Diameter (mm)15d115 mmd726 mmZ2.5 mmu3 mmb120 mmd418.5 mmd642 mmh2100 mml2 max.62.5 mml3 min.30 mmB314 mmThread (G)M20x1.5Angle6.5 °Weight0.31 KgBasic dynamic load rating (C)5.49 kNBasic static load rating (C0)3.28 kNLimiting speed980 r/minCalculation factor (Y)2.07 Cross-reference to other manufacturer'…
Contact Us Now !

Product description

TSM 15-00 BB-E ISB Angle 6.5 ° Self aligning ball bearings

Bearing numberTSM 15-00 BB-E
BrandISB
Bore Diameter (mm)15
d115 mm
d726 mm
Z2.5 mm
u3 mm
b120 mm
d418.5 mm
d642 mm
h2100 mm
l2 max.62.5 mm
l3 min.30 mm
B314 mm
Thread (G)M20x1.5
Angle6.5 °
Weight0.31 Kg
Basic dynamic load rating (C)5.49 kN
Basic static load rating (C0)3.28 kN
Limiting speed980 r/min
Calculation factor (Y)2.07

Cross-reference to other manufacturer’s part number

XSA 14 0644 N Thrust roller bearings

Dynamic load rating radial (C):185 kN , Dynamic load rating axial (C):290 kN , Static load rating radial (C0):395 kN , Weight:52 Kg
TM-QJ314C4U35K Angular contact ball bearings

D:150.000 mm , d:70.000 mm , Width :35.000mm , C:35.000 mm , B:35.000 mm
TR 425630 Needle roller bearings

Weight:0.183 Kg , Da max.:52 mm , Basic static load rating (C0):90.1 kN , Basic dynamic load rating (C):53.8 kN
YH-78 Needle roller bearings

D:17.462 mm , Width :12.7mm , Fw:11.112 mm , C:12.7 mm , Weight:0.011 Kg , Basic dynamic load rating (C):11.4 kN
TLA 3020 UU Needle roller bearings

Basic static load rating (C0):24.5 kN , Basic dynamic load rating (C):14.1 kN , D:37 mm , C:20 mm , Weight:0.039 Kg
24132-E1-2VSR-H40 Spherical roller bearings

Fatigue load limit (Pu):168 , Limiting speed:550 r/min , Basic static load rating (C0):1800 kN , Calculation factor (e):0.37 , Calculation factor (Y0):1.76 , Calculation factor (Y1):1.8
ZB2.22.1088.400-1SPPN Thrust ball bearings

Hd:80 mm , Hi:88 mm , Ht:97 mm , He:88 mm
3303-B-2RSR-TV Angular contact ball bearings

Limiting speed:11000 r/min , Basic dynamic load rating (C):20.2 kN , Basic static load rating (C0):11.9 kN , Weight:0.2 Kg
NP804861/H914811 Tapered roller bearings

Outer Diameter :152.4mm , Brand:Timken , D:152.4 mm
AST650 607580 Plain bearings

ID Chamfer Angle (B deg.):15 , Bearing Length Tolerance (B tol.) – -0.10 / -0.30:0.10 / 0.30 , Material:Cast bronze with solid lubricant inserts. , OD Chamfer Length (Co):2.000 , ID Chamfer Length (Ci):1.200 , Bearing Length, Nominal (B):80.000
