Home > Angular contact ball bearings > VEX 60 7CE1 SNFA 60x95x18mm (Grease) Lubrication Speed 20 000 r/min Angular contact ball bearings
VEX 60 7CE1 SNFA 60x95x18mm  (Grease) Lubrication Speed 20 000 r/min Angular contact ball bearings

VEX 60 7CE1 SNFA 60x95x18mm (Grease) Lubrication Speed 20 000 r/min Angular contact ball bearings

Bearing numberVEX 60 7CE1Size (mm)60x95x18BrandSNFABore Diameter (mm)60Outer Diameter (mm)95Width (mm)18d60 mmD95 mmB18 mmC18 mma19 mmd172.7 mmr1 min.1.1 mmr2 min.1.1 mmr3 min.0.6 mmr4 min.0.6 mmD182.2 mmda min.66 mmDa max.89 mmdb min66 mmra max.1.1 mmrb max.0.6 mmdh8.5 mmDb max90.8 mmWeight0.42 KgBasic dynamic load rating (C)17.2 kNBasic static lo…
Contact Us Now !

Product description

VEX 60 7CE1 SNFA 60x95x18mm (Grease) Lubrication Speed 20 000 r/min Angular contact ball bearings

Bearing numberVEX 60 7CE1
Size (mm)60x95x18
BrandSNFA
Bore Diameter (mm)60
Outer Diameter (mm)95
Width (mm)18
d60 mm
D95 mm
B18 mm
C18 mm
a19 mm
d172.7 mm
r1 min.1.1 mm
r2 min.1.1 mm
r3 min.0.6 mm
r4 min.0.6 mm
D182.2 mm
da min.66 mm
Da max.89 mm
db min66 mm
ra max.1.1 mm
rb max.0.6 mm
dh8.5 mm
Db max90.8 mm
Weight0.42 Kg
Basic dynamic load rating (C)17.2 kN
Basic static load rating (C0)12.9 kN
(Grease) Lubrication Speed20 000 r/min
(Oil) Lubrication Speed31 000 r/min

Cross-reference to other manufacturer’s part number

VEX 10 /NS 7CE3 Angular contact ball bearings

Basic dynamic load rating (C):2.86 kN , (Grease) Lubrication Speed:98 000 r/min , (Oil) Lubrication Speed:150 000 r/min , Basic static load rating (C0):1.14 kN
T.A.C. 235 Plain bearings

Weight:0.96 Kg , Angle:6 ° , C1:21 mm , Basic dynamic load rating (C):80 kN
29464 Thrust roller bearings

Weight:181 Kg , Da max.:495 mm , ra max.:6 mm , da min.:435 mm , Basic static load rating (C0):14 200 kN , Basic dynamic load rating (C):3 700 kN
BLF202 Bearing units

f0:13.2 , (Refer.)Unit mass(kg):0.25 , C0r:4.80 , Cr:9.55
1207 Self aligning ball bearings

Width :17mm , Outer Diameter :72mm , d:35 mm , C:17 mm , D:72 mm , B:17 mm
230/750E Cylindrical roller bearings

Calculation factor (Y1):3.1 , Calculation factor (e):0.22 , (Oil) Lubrication Speed:450 r/min , (Grease) Lubrication Speed:340 r/min , Calculation factor (Y0):3.03
150RUB40 Spherical roller bearings

Basic dynamic load rating (C):375 kN , B:75 mm , C:75 mm , r min.:2.1 mm
15578/15520 Tapered roller bearings

Basic static load rating (C0):44 kN , (Grease) Lubrication Speed:9360 r/min , Weight:0.23 Kg , Basic dynamic load rating (C):39 kN
22219CW33 Spherical roller bearings

C:43 mm , d:95 mm , Width :43mm , B:43 mm , D:170 mm
AR 7 25 52 Needle roller bearings

Eb:29 mm , Basic dynamic load rating (C):32.5 kN , Weight:0.07 Kg , Basic static load rating (C0):122 kN
