W635-2Z SKF 5x19x6mm  Da max. 17 mm Deep groove ball bearings

W635-2Z SKF 5x19x6mm Da max. 17 mm Deep groove ball bearings

Bearing numberW635-2ZSize (mm)5x19x6BrandSKFBore Diameter (mm)5Outer Diameter (mm)19Width (mm)6d5 mmD19 mmB6 mmC6 mmd1– mmd28.5 mmr1 min.7 mmr2 min.7 mmD116.5 mmD20.3 mmda min.8.4 mmDa max.17 mmra max.0.3 mmWeight0.008 KgBasic dynamic load rating (C)2.34 kNBasic static load rating (C0)0.88 kNFatigue load limit (Pu)0.038Reference speed85000 r/minL…
Contact Us Now !

Product description

W635-2Z SKF 5x19x6mm Da max. 17 mm Deep groove ball bearings

Bearing numberW635-2Z
Size (mm)5x19x6
BrandSKF
Bore Diameter (mm)5
Outer Diameter (mm)19
Width (mm)6
d5 mm
D19 mm
B6 mm
C6 mm
d1– mm
d28.5 mm
r1 min.7 mm
r2 min.7 mm
D116.5 mm
D20.3 mm
da min.8.4 mm
Da max.17 mm
ra max.0.3 mm
Weight0.008 Kg
Basic dynamic load rating (C)2.34 kN
Basic static load rating (C0)0.88 kN
Fatigue load limit (Pu)0.038
Reference speed85000 r/min
Limiting speed43000 r/min
Calculation factor (f0)12

Cross-reference to other manufacturer’s part number

NKIB 5912 Complex bearings

Dynamic load rating axial (C):9.5 kN , Static load rating radial (C0):102.6 kN , Dynamic load rating radial (C):57 kN , Static load rating axial (C0):10.26 kN
UKF305 Bearing units

Weight:1.4 Kg , A2:16 mm , Basic dynamic load rating (C):21.2 kN , Basic static load rating (C0):10.9 kN
SA0024 Angular contact ball bearings

D:68 mm , C:37 mm , B:37 mm , Width :37mm , d:39 mm , Outer Diameter :68mm
KBH 13-PP Linear bearings

L:32 mm , H:6 mm , D1:43 mm , Basic dynamic load rating (C):0.52 kN , W:29 mm , Weight:0.081 Kg
21317K Spherical roller bearings

Product Group – BDI:B04311 , Weight / Kilogram:0 , EAN:4547359260878 , Manufacturer Name:NTN , Minimum Buy Quantity:N/A , BDI Inventory:0.0
1621-Z Deep groove ball bearings

B:11.112 mm , Weight:0.049 Kg , Basic dynamic load rating (C):7.64 kN , r min.:0.3 mm , C:11.112 mm
KGBO12-PP-AS Bearing units

Weight:0.09 Kg , Basic dynamic load rating (C):0.6 kN , Thread (K5):M5 , JL4:6.5 mm
160BIC647 Deep groove ball bearings

Weight:48.8 Kg , B:69.85 mm , C:69.85 mm , Basic dynamic load rating (C):400 kN
16005ZZ Deep groove ball bearings

D:47 mm , d:25 mm , C:8 mm , B:8 mm
ZARF 3080 TN Complex bearings

Static load rating axial (C0):95.95 kN , (Grease) Lubrication Speed:1 700 r/min , Dynamic load rating axial (C):37 kN , Dynamic load rating radial (C):23.1 kN , Static load rating radial (C0):39.4 kN
