X33216/Y33216 Timken a – 10.7 mm 80x140x46mm  Tapered roller bearings

X33216/Y33216 Timken a – 10.7 mm 80x140x46mm Tapered roller bearings

Bearing numberX33216/Y33216Size (mm)80x140x46BrandTimkenBore Diameter (mm)80Outer Diameter (mm)140Width (mm)46d80 mmD140 mmT46 mmB46 mmC35 mmR2.5 mmr2 mma -10.7 mmDa135 mmdb97 mmda89 mmDb125 mmAa5.4 mmAb2.8 mmWeight2.94 KgBasic static load rating (C0)409 kNFactor (G1)142.7Factor (G2)38Factor (Cg)0.0248Factor (K)1.37Basic dynamic load rating (C90)71…
Contact Us Now !

Product description

X33216/Y33216 Timken a – 10.7 mm 80x140x46mm Tapered roller bearings

Bearing numberX33216/Y33216
Size (mm)80x140x46
BrandTimken
Bore Diameter (mm)80
Outer Diameter (mm)140
Width (mm)46
d80 mm
D140 mm
T46 mm
B46 mm
C35 mm
R2.5 mm
r2 mm
a –10.7 mm
Da135 mm
db97 mm
da89 mm
Db125 mm
Aa5.4 mm
Ab2.8 mm
Weight2.94 Kg
Basic static load rating (C0)409 kN
Factor (G1)142.7
Factor (G2)38
Factor (Cg)0.0248
Factor (K)1.37
Basic dynamic load rating (C90)71.3
Basic dynamic load rating (Ca90)51.9
Basic dynamic load rating (C1)275 kN
Calculation factor (e)0.43
