XAD32010X/YKB32010X Timken r 0.5 mm 50x82x21.5mm  Tapered roller bearings

XAD32010X/YKB32010X Timken r 0.5 mm 50x82x21.5mm Tapered roller bearings

Bearing numberXAD32010X/YKB32010XSize (mm)50x82x21.5BrandTimkenBore Diameter (mm)50Outer Diameter (mm)82Width (mm)21.5d50 mmD82 mmT21.5 mmB20 mmC17 mmR1.5 mmr0.5 mma -2 mmDa77 mmdb59 mmda56 mmDb76 mmAa0.9 mmAb2.1 mmWeight0.42 KgBasic static load rating (C0)92.7 kNFactor (G1)34Factor (G2)20.3Factor (Cg)0.0217Factor (K)1.38Basic dynamic load rating (…
Contact Us Now !

Product description

XAD32010X/YKB32010X Timken r 0.5 mm 50x82x21.5mm Tapered roller bearings

Bearing numberXAD32010X/YKB32010X
Size (mm)50x82x21.5
BrandTimken
Bore Diameter (mm)50
Outer Diameter (mm)82
Width (mm)21.5
d50 mm
D82 mm
T21.5 mm
B20 mm
C17 mm
R1.5 mm
r0.5 mm
a –2 mm
Da77 mm
db59 mm
da56 mm
Db76 mm
Aa0.9 mm
Ab2.1 mm
Weight0.42 Kg
Basic static load rating (C0)92.7 kN
Factor (G1)34
Factor (G2)20.3
Factor (Cg)0.0217
Factor (K)1.38
Basic dynamic load rating (C90)16.8
Basic dynamic load rating (Ca90)12.2
Basic dynamic load rating (C1)64.7 kN
Calculation factor (e)0.42

Cross-reference to other manufacturer’s part number

AST20 16080 Plain bearings

Material:Carbon steel shell with POM plastic liner , ID Chamfer Length (Ci):0.800 , OD Chamfer Length (Co):1.800 , Lube Hole Dia. (dl):9.500 , ID Chamfer Angle (B deg.):45
231/750EK Cylindrical roller bearings

Calculation factor (Y0):2.2 , (Oil) Lubrication Speed:280 r/min , Calculation factor (Y1):2.25 , Calculation factor (e):0.3
K89422-M Thrust roller bearings

Dw:24 mm , Weight:3.3 Kg , Basic static load rating (C0):3397.8 kN , Basic dynamic load rating (C):998.5 kN
NUP 2316 ECP Thrust ball bearings

Fatigue load limit Pu:55 kN , Mass bearing:6 kg , Basic static load rating C0:440 kN , Axial load factor Y:0.4 , Calculation factor kr:0.25 , Limiting value e:0.3
24144MB Spherical roller bearings

Max Speed (Oil) (X000 RPM):1 , Weight (g):93.730.00 , Static Load Rating (Cor):3.109.000 , Max Speed (Grease) (X000 RPM):1 , Material:52100 Chrome steel. or equivalent
B-208 Needle roller bearings

Weight:0.026 Kg , C:12.7 mm , (Grease) Lubrication Speed:2300 r/min , Basic dynamic load rating (C):18.6 kN , Basic static load rating (C0):36.6 kN
2305-2RS Self aligning ball bearings

Basic static load rating (C0):6.55 kN , Basic dynamic load rating (C):24.2 kN , D:62 mm , B:24 mm , C:24 mm , Weight:0.361 Kg
17BKM2517JBUUH Needle roller bearings

Basic dynamic load rating (C):7.3 kN , C:16.7 mm , Weight:0.02 Kg , Basic static load rating (C0):7.9 kN
16014 Deep groove ball bearings

B:13 mm , Weight:0.43 Kg , C:13 mm , r min.:0.6 mm , Basic dynamic load rating (C):27.9 kN , D:110 mm
2209K Self aligning ball bearings

B:23.000 mm , D:85.000 mm , d:45.000 mm , C:23.000 mm , Width :23.000mm
