Home>Products>Mounted Units>TIMKEN YASM1 15/16 image

TIMKEN YASM1 15/16 image

Back to product page

You Might Also Like

Information techniques TIMKEN YASM1 15/16

D1 - Flange Outer Diameter:5.4650 in
B - Cone Width:1.3125 in
C - Cup Width:1.0313 in
C1 - Cup Flange Width:0.2188 in
T1 - Bearing Width:1.3125 in
T - Bearing Width to Flange:0.5000 in
R - Cone Backface To Clear Radius1:0.03 in
r - Cup Backface To Clear Radius2:0.130 in
da - Cone Frontface Backing Diameter:3.54 in
db - Cone Backface Backing Diameter:3.58 in
Da - Cup Frontface Backing Diameter:5.16 in
Ab - Cage-Cone Frontface Clearance:0.12 in
Aa - Cage-Cone Backface Clearance:0.08 in
a - Effective Center Location3:-0.17 in
C90 - Dynamic Radial Rating (90 million revolutions)4:12500 lbf
C1 - Dynamic Radial Rating (1 million revolutions)5:48100 lbf
C0 - Static Radial Rating:58900 lbf
Ca90 - Dynamic Thrust Rating (90 million revolutions)6:8640 lbf
K - Factor7:1.44
e - ISO Factor8:0.4
Y - ISO Factor9:1.48
G1 - Heat Generation Factor (Roller-Raceway)10:119
G2 - Heat Generation Factor (Rib-Roller End):29.2
Cg - Geometry Factor11:0.127
