Information techniques TIMKEN ER24 SGT

d1:108.25 mm
d2:91.13 mm
D1:128.9 mm
a:68 mm
r1,2 - min.:2.1 mm
r3,4 - min.:1.1 mm
da - min.:87 mm
Da - max.:148 mm
Db - max.:153 mm
ra - max.:2 mm
rb - max.:1 mm
Basic dynamic load rating - C:132 kN
Basic static load rating - C0:104 kN
Fatigue load limit - Pu:4.2 kN
Reference speed:5300 r/min
Limiting speed:5300 r/min
Calculation factor - kr:0.1
Calculation factor - ka:1.6
Calculation factor - e:1.14
Calculation factor - X:0.35
Calculation factor - Y0:0.26
Calculation factor - Y1:0.55
Calculation factor - Y2:0.57
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:3.07
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 3 | ISO P6
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Polymer
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Preload:Light
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:75MM Bore; 160MM Outside Diameter; 37MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 3 | ISO P6; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7315 BEGAP
Weight / LBS:6.755
Bore:2.953 Inch | 75 Millimeter
Width:1.457 Inch | 37 Millimeter
Outside Diameter:6.299 Inch | 160 Millimeter
bore diameter::75 mm
radial static load capacity::104 kN
outside diameter::160 mm
cage material::Nylon
overall width::37 mm
outer ring width::37 mm
contact angle::40 °
maximum rpm::5300 RPM
row type & fill slot::Single-Row Non-Fill Slot
finish/coating::Uncoated
internal clearance::C0
precision rating::ABEC 3 (ISO Class 6)
closure type::Open
fillet radius::2 mm
radial dynamic load capacity::132 kN
series::73
d1 ≈:108.25 mm
d2 ≈:91.13 mm
D1 ≈:128.9 mm
r1,2 min.:2.1 mm
r3,4 min.:1.1 mm
da min.:87 mm
Da max.:148 mm
Db max.:153 mm
ra max.:2 mm
rb max.:1 mm
Basic dynamic load rating C:132 kN
Basic static load rating C0:104 kN
Fatigue load limit Pu:4.15 kN
Calculation factor A:0.171
Calculation factor kr:0.1
Calculation factor e:1.14
Calculation factor X:0.57
Calculation factor Y0:0.52
Calculation factor Y2:0.93
Calculation factor Y1:0.55
Mass bearing:3.2 kg
