NTN UCF317D1 - Leader Industrial Manufacture

✖

NTN UCF317D1 image

Information techniques NTN UCF317D1

UPC Code:0883450507950
Type E Open Cover Number:EUDR-3 15/16
Nose Diameter:7.69 in
Nose Bore Diameter:6.37 in
Dimension B:6-1/4 in
Dimension H:10-7/8 in
Dimension A:4-1/2 in
Dimension N2:6.630 in
Dimension J:9-3/8 in
Dimension A3:1-1/2 in
Bolt Diameter:3/4 in
Dimension E:2-11/16 in
Dimension A1:1 in
Dimension D 1:8-1/8 in
Dimension d1:6-1/16 in
Dimension A2:1-13/16 in
Dimension Ac:5.925 in
Dimension d2:7.43 in
e:0.49
X (if Fa/Fr ≤ e):0.87
Y (if Fa/Fr ≤ e):1.77
X (if Fa/Fr > e):0.7
Y (if Fa/Fr > e):2.14
K Factor:1.23
C90 Dynamic Load Rating2:26900 lb
C0 Static Load Rating:154000 lb
Fa-max Maximum Permissible Thrust Load3:6908 lb
Fr-max Maximum Allowable Slip Fit Radial Load4:22000 lb
Max. Speed5:1530 rpm
Note:Note: All units have a 1/8 pipe thread grease fittingThe Maximum Permissible Thrust Load applies to conditions of slip fit with set screw mounting or in applications where a large moment loading occur
